Founded by engineers with decades of hands on semiconductor experience.
Seminovaa is a physical design and signoff partner built for precision from day one. We help chip teams close floorplans, hit timing, and reach clean signoff at the pace advanced nodes demand.
Seminovaa is a specialized semiconductor design services company built around deep Physical Design and signoff expertise: floorplanning, timing closure with full STA signoff, power optimization, DRC, LVS and EM/IR signoff, and pre-silicon DFT at advanced process nodes. We partner with global semiconductor leaders to deliver high performance silicon that is right the first time, from RTL through GDSII.
One discipline, held to a signoff standard. A deliberate path to a full ASIC Design House.
We do not spread ourselves across the whole flow. We go deep on Physical Design and signoff, and we build outward from that strength.
01 / Core
RTL to GDSII & Signoff Closure
Floorplanning, placement, CTS, routing and ECO. Timing closure across corners with full STA signoff. Power optimization. DRC, LVS and EM/IR signoff. Pre-silicon DFT: scan insertion, ATPG and BIST planning, so test coverage is built in, not bolted on at the end.
Floorplanning
CTS & routing
STA signoff
DRC / LVS
EM/IR
Scan & ATPG
02
Test Engineering & Post Silicon Validation
Support for silicon bring up, characterization and validation, from tapeout through production readiness.
Silicon bring-up
Characterization
Validation
Our Scope
We take your design to tapeout ready GDSII. On purpose, we stop there.
We take your design from spec or RTL through to a tapeout ready GDSII: floorplanning, place and route, timing closure with STA signoff, power optimization, pre-silicon DFT, and full signoff across DRC, LVS and EM/IR. Manufacturing, packaging and test remain with you or your foundry partner of choice. That boundary is a choice, not a limitation. It keeps our focus, and our accountability, exactly where chip teams need it most.
Spec / RTLStage 1
➜
Our scope, start to finishSeminovaaPhysical Design & Signoff
➜
Tapeout ready GDSIIStage 3
➜
Manufacturing, packaging & testOutside our scope, by design. With you or your foundry partner.
Our Vision
Engineers who know their tools, including the newest ones.
EDA tools keep getting smarter, and we see that as an advantage for our clients, not a threat to our engineers. We train our Physical Design team to use AI assisted flows for the repetitive, data heavy parts of the job, so more of their time goes into the judgment calls that decide whether a block actually signs off clean. We are building Seminovaa into the ASIC Design House Indian semiconductor teams turn to first, a position we intend to earn through the blocks we actually deliver, not the ones we promise.
Faster exploration
Faster floorplans, more options tried
AI assisted exploration inside our EDA flow lets us try more floorplan and placement options before we commit, instead of settling for the first one that closes.
Cleaner closure
Quicker triage on timing and ECOs
Automated report analysis and violation classification help our engineers get to the root cause of a timing or DRC issue faster, so closure cycles get shorter, not shallower.
Human judgment
Signoff accountability stays with people
Tools accelerate the work. The decision on whether a block is ready to sign off, and the accountability that comes with it, stays with our senior engineers.
We are not asking permission to become a design house. We are earning it through the work we deliver.
The engineers who get the most out of these tools, rather than the ones who ignore them, are the ones clients will want on their hardest blocks. That is the standard we are holding our whole team to.
How We Work With You
Engagement models shaped around how you like to work.
Dedicated Team
Individual Seminovaa engineers embedded in your team, on site or offshore, integrated into your workflow and reporting into your program, sized up or down as your needs change, on a time and material basis.
Project-Based
Fixed scope, timeline and cost for one block or a defined set of blocks, RTL/netlist through tapeout ready GDSII, with payment tied to agreed milestones.
Offshore Development Center
A standing Seminovaa team with its own lead, built around your program and dedicated to it long term, functioning as your India engineering site rather than a set of individual placements.
BEYOND THESE
For a full program, we can also talk Turnkey.
Complete ownership of a defined program, from RTL/netlist to tapeout ready GDSII, under one roof. This is structured deal by deal. Tell us what you need, and we will tell you honestly whether we are the right fit today.
Founded to be a catalyst in the evolving semiconductor landscape.
Seminovaa combines deep technical expertise, a passion for precision, and a commitment to delivering value from day one, principles that have guided the company since it started.
Mission
To deliver transparent, agile, and premium design execution that bridges the global talent gap, and to become the world's most respected company in the semiconductor domain.
Vision
To be the premier Physical Design and signoff partner for complex ASIC and SoC programs, delivering tapeout ready silicon from India to the world.
Leadership
Experienced engineers and domain specialists.
Our leadership brings decades of semiconductor product development, engineering services and industry building.
Founder & CEO
Abutaahir Bhadusha
More than 25 years in semiconductor product development, engineering services and business growth, with over 50 semiconductor design projects delivered across mobile, communication, networking and storage. He founded Seminovaa in 2025 to deliver high-value semiconductor design and development from India to the global market.
Read more
He has held key leadership roles at Cadence, Qualcomm, LSI Corporation (USA), RapidBridge (USA), Open-Silicon and Avant! (acquired by Synopsys), expanding engineering capabilities and organizational presence across India and the U.S.
Education: B.E. from Vellore Institute of Technology (VIT) and the PGP program (Executive MBA equivalent) from UCLA.
Technical Advisor
Dr. Satya Gupta
Part of the worldwide semiconductor and electronics industry for more than 40 years. After 12 years at Intel, he co-founded four companies: Intel Micro-Electronics, Open-Silicon, Concept-2-Silicon and SenZopt. He is currently president of the VLSI Society of India.
Read more
Founding member of the India Semiconductor Association (IESA) in 2005 and its chairman in 2012-13 and 2020-21. He also co-founded and served as CEO of the EPIC Foundation, a non-profit for developing Indian electronics products.
His mission is to make India an electronics and semiconductor product nation, taking VLSI design education to 500+ colleges and establishing "1-TOPS: One Chip Tape-Out Per Student" before graduation.
Recognition includes the IEEE Gordon Bell award for the fastest supercomputer, Best Private Semiconductor Company (Open-Silicon, Global Semiconductor Alliance), the Distinguished Alumni Award from BITS Pilani, and Lifetime Achievement Awards from the VLSI Society of India, DVCON and Mentor Graphics.
He is visiting faculty at IIT Roorkee, IIT Gandhinagar and Gati Shakti University, and sits on the Board of Governors at BMS-ITM, Bangalore.
Get in touch
Let's talk about your next tapeout.
Whether it is a defined work package, a team extension, or an early conversation about where Seminovaa can help, we would like to hear from you.
